RIC-610MK
Rated Voltage: 1V -4.5V
Application:Massager／Pager／PCB Mounted／Mobile／Personal care equipment／Electronics products
Options: specifcations, silicons set, surface mounting brackets,shaft length, counter-weight;
Motor Specifications
| Model | RIC-610MK-013850 | RIC-610MK-030100 | RIC-610MK-015113 | RIC-610MK-030157 | |
|---|---|---|---|---|---|
| Rated Voltage | V | 1.3 | 3 | 1.5 | 3 |
| Rated Speed | rpm | 8500 | 10000 | 11300 | 15700 |
| Rated Current | mA | 80 | 70 | 70 | 50 |
| Start Voltage | V | 1 | 1.5 | 0.8 | 1 |
| Stall Current | mA | 110 | 105 | 135 | 100 |
| Terminal Resistance | Ω | 11.5 | 35 | 12 | 26.5 |
Outline Drawing
REMARKS
Specifications, shaft dimensions, screw holes, connector, gears and other components can be customized to meet customer specific requirements.
